Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: SG4P109N LF
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Number Of Ports: |
Quad Port |
Speed: |
10/100/1000 Base-T |
Pins No: |
72 |
AutomDX: |
Yes |
Construction: |
OPEN FRAME |
Free Samples: |
Available 1-3 Pcs |
Number Of Ports: |
Quad Port |
Speed: |
10/100/1000 Base-T |
Pins No: |
72 |
AutomDX: |
Yes |
Construction: |
OPEN FRAME |
Free Samples: |
Available 1-3 Pcs |
The G4P109N LF quad port Ethernet component features a 1:1 turns ratio for both transmitter and receiver functions. Housed in an open frame construction and designed for LAN Ethernet applications without Power over Ethernet (PoE) capabilities. With a speed rating of 10/100/1000 Base-T, it offers versatile connectivity options. Packaged in a convenient tape & reel format, each port includes 16 cores for efficient data transmission. The component supports AutomDX functionality for automatic detection and configuration. With 72 pins, this Ethernet component is optimized for high-performance networking applications.
|
Turns Ratio |
TX=1CT:1CT |
|
OCL |
350uH min @ 100KHz 0.2V with 8mA bias |
|
Insertion Loss |
0.5-100MHz:-1.1dB Max |
|
Return Loss |
0.5-30MHz: -18dB Min |
|
Crosstalk |
0.5-40MHz: -35dB Min |
|
CMRR |
0.5-100MHz: -30dB Min |
| Hipot | 1500Vrms |
| Operating Temperature | -40℃~85℃ |
|
G4P109N LF Drawing-Mechanical:
G4P109N LF Drawing-Schematic:
|
|
